Model:KXZ-350B

Automatic Large Size Box Foods Cartoning Machine

Encasing Speed:
20-30box/min
Box quality requirement:
250-450g/m2
Box dimension range:
(200-350)mm×(250-350)mm×(30-90)mm
Contact Us Watch The Video
CE certification
We have CE certification authorized by the European Union.
ISO9001
We have ISO9001 quality management system certification
Quality Service
KAIXIANG provides you with the most comprehensive service.
Description

The KXZ - 350B Automatic Large Size Box Foods Cartoning Machine specializes in efficiently packing large - sized food products into cartons. Its PLC - controlled system ensures precise and stable operation. It can be integrated into automatic production lines, accommodating diverse food items like large - pack snacks and family - sized cereals.

In snack manufacturing, the KXZ - 350B efficiently packs multi - flavor chip assortments into large boxes. For cereal producers, it precisely loads family - sized boxes, optimizing production throughput and reducing packaging errors.

Main Technical Parameter

Encasing Speed

20-30box/min

Box

Quality requirement

250-450g/m2

(according to its dimension to confirm)

Dimension range

 (L×W×H)

(200-350)mm×(250-350)mm×(30-90)mm

can customize according to your requirement

Compressed air

Working pressure

≧0.6mpa

Air consumption

20m3/h

Power supply

380V 50Hz

Motor power

1.5KW

Machine dimension (L×w×H)

6080*1360*1900mm

Machine weight

1500KGS

Standard features
Box close
Box loader
Output
Product loader
Push into box
